Low-noise DC Electric Linear Actuator 12V 6000N Thrust For Home Office Automation

Informazioni di base

Luogo di origine:	Cina
Marca:	Linsheng Auto II MaxM
Numero di modello:	LS-PAT-1

Quantità di ordine minimo:	1 pezzo
Prezzo:	79USD/PC~299USD/PC
Imballaggi particolari:	Cartone
Tempi di consegna:	2 settimane
Termini di pagamento:	L/C, T/T, PayPal
Capacità di alimentazione:	500 pezzi/mese

Miglior prezzo Contattaci

Voltaggio:	CC 12V-24V	Spinta:	2000N / 4000N / 6000N
Livello di rumore:	≤58dB	Colpo:	50 mm - 1000 mm
Mini. lunghezza ritirata:	≧ 230mm	Opzioni:	Azionamento manuale
Interruttori limite:	Incorporato	Uscita di Singal:	Sensori di vaso / sala
Temperatura di lavoro:	-25℃~+65℃	Max. VELOCITÀ:	7 mm/s (carico libero); 3 mm/s (carico completo)
Valutazione IP:	IP66 / IP69	Lunghezza del cavo:	Cavo dritto 2000mm
Corrente nominale:	Max. 6.5a (24V)	Caratteristiche:	Compatta, silenziosa, resistente alle intemperie, durata
Evidenziare:	≤58dB Electric Linear Actuator , 6000N Thrust DC Linear Actuator , Home Office Automation Linear Actuator

Low-noise DC Electric Linear Actuator 12V 6000N Thrust For Home Office Automation

LS-PAT-1 DC actuator is an industrial-grade linear actuator engineered for applications demanding a quiet and resilient solution. It combines robust construction, a high IP69K rating, and strong thrust, making it the ideal choice for light industrial automation.

Specifications:

Working voltage	12V / 24V DC
Load capacity	Max. 6000N (Push); 4000N(Pull)
Stroke	50mm - 1000mm
Mini. installation length	≧230mm
Max. speed	3mm/s (Full load); 7mm/s (No load)
Limit switches	Built in
Output signals	Hall sensors / POT
Noise level	≤58dB
Working temperature	-25℃~+65℃
Options	Manual Drive

Features:

* IP rating up to IP69 for demanding environment

* Max. load capacity is 600KG (Push)

* Travle quietly

* Long customizable stroke

Low-noise DC Electric Linear Actuator 12V 6000N Thrust For Home Office Automation 0

Low-noise DC Electric Linear Actuator 12V 6000N Thrust For Home Office Automation 1

Low-noise DC Electric Linear Actuator 12V 6000N Thrust For Home Office Automation 3

About us:
Linsheng Auto (LINSHENG INTERNATIONAL ENTERPRISE CO.,LTD) is specialized in Auto motion, motion remote control systems, automobile safety and security electronics for more than 10 years. With an experienced R&D department of 19 engineers team, we can provide customized design and molding to support your OEM/ODM projects.

Support and Services:
All our products come with a one-year warranty. We provide technical support and services for Linear Actuator Controllers. Our team of engineers and technicians are available to help you troubleshoot any problems you may be having with your Linear Actuator Control box.

Packing and Shipping:
All our products are packaged carefully before shipping. The box is sealed with tape and labeled with the product name and shipping address. Your item will be shipped via UPS, FedEx , DHL or other shipping courier you may prefer.
